NordicTrack Professional 3000 3500 4000 Treadmill Dc Drive Motor 234976
Condition New
Used on the following models: FreeMotion 3000 XLS Treadmill - VFMTL11060 3500 XLS Treadmill - VFMTL12060 NordicTrack® Professional Series 3500 - NTL349050 Professional Series 4000 - NTL399050 Motor housing diameter measures 115mm (4.527"). Removable, heavy (8.4 lb.) steel flywheel mounted onto tapered motor shaft by means of retention screw. Flywheel measures 172mm (6.772") dia. x 36mm thick. Flywheel has 2.1" O.D. ten-groove pulley for serpentine belt. SPECIFICATIONS Power 3.5 HP (2611 W) Voltage 150 VDC Amperage 20.1 Amps Speed 4500 RPM @ 150 VDC, No Load Rotation Reversible Enclosure OFC Duty Treadmill Mount Two 7mm Holes in Housing on 3" Centers Shaft 17mm dia. x 35mm overall length, Tapers from 17mm to 16mm in 24mm, End tapped 3/8"-16 Size 12-1/2" x 6-3/4" O.D. Shpg. 34 lbs.
NordicTrack Professional 3000 3500 4000 Treadmill Dc Drive Motor 234976
Condition New
Used on the following models: FreeMotion 3000 XLS Treadmill - VFMTL11060 3500 XLS Treadmill - VFMTL12060 NordicTrack® Professional Series 3500 - NTL349050 Professional Series 4000 - NTL399050 Motor housing diameter measures 115mm (4.527"). Removable, heavy (8.4 lb.) steel flywheel mounted onto tapered motor shaft by means of retention screw. Flywheel measures 172mm (6.772") dia. x 36mm thick. Flywheel has 2.1" O.D. ten-groove pulley for serpentine belt. SPECIFICATIONS Power 3.5 HP (2611 W) Voltage 150 VDC Amperage 20.1 Amps Speed 4500 RPM @ 150 VDC, No Load Rotation Reversible Enclosure OFC Duty Treadmill Mount Two 7mm Holes in Housing on 3" Centers Shaft 17mm dia. x 35mm overall length, Tapers from 17mm to 16mm in 24mm, End tapped 3/8"-16 Size 12-1/2" x 6-3/4" O.D. Shpg. 34 lbs.
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Condition New
Used on the following models: FreeMotion 3000 XLS Treadmill - VFMTL11060 3500 XLS Treadmill - VFMTL12060 NordicTrack® Professional Series 3500 - NTL349050 Professional Series 4000 - NTL399050 Motor housing diameter measures 115mm (4.527"). Removable, heavy (8.4 lb.) steel flywheel mounted onto tapered motor shaft by means of retention screw. Flywheel measures 172mm (6.772") dia. x 36mm thick. Flywheel has 2.1" O.D. ten-groove pulley for serpentine belt. SPECIFICATIONS Power 3.5 HP (2611 W) Voltage 150 VDC Amperage 20.1 Amps Speed 4500 RPM @ 150 VDC, No Load Rotation Reversible Enclosure OFC Duty Treadmill Mount Two 7mm Holes in Housing on 3" Centers Shaft 17mm dia. x 35mm overall length, Tapers from 17mm to 16mm in 24mm, End tapped 3/8"-16 Size 12-1/2" x 6-3/4" O.D. Shpg. 34 lbs.
